Name: SFP+ 10G BIDI 5KM Optical Transceiver with LC Connector for High-Speed Data Transmission
Brand: Shenzhen HiLink Technology Co.,Ltd.
SKU: HL-SFP-BXU-L5/HL-SFP-BXD-L5
Price: 5.00 USD
Availability: InStock

Para casa > produtos > Módulo óptico do transceptor >

SFP+ 10G BIDI 5KM Optical Transceiver with LC Connector for High-Speed Data Transmission

Lugar de origem:

Marca:

HiLink or OEM

Certificação:

CE FCC ROSH

Número do modelo:

HL-SFP-BXU-L5/HL-SFP-BXD-L5

Contacte-nos

Solicite um orçamento

SFP+ 10G BIDI 5KM Optical Transceiver with LC Connector for High-Speed Data Transmission

Detalhes do produto

Nome do produto:

Transceptor óptico SFP+ 10G BIDI 5KM

Velocidade de dados:

10g

Transmissão:

5 km

Tipo de conector:

Comprimento de onda:

T1270/R1330

Compatível:

Cisco, Juniper, Arista, Huawei, etc.

Termos de pagamento e envio

Quantidade de ordem mínima

1 par

Preço

US$5.00~US$6.00/pair

Detalhes da embalagem

Pacote normal ou OEM

Tempo de entrega

5-8 dias úteis

Termos de pagamento

T/T, PayPal, Western Union

Habilidade da fonte

2000 pares por semana

PRODUTOS CONEXOS

SFP+ 10G BIDI 5KM Optical Transceiver with LC Connector for High-Speed Data Transmission

Obtenha o melhor preço

10Gb/s XFP Bi-Directional Transceiver 40km Reach TX1270/1330nm RX1330/1270nm RoHS Compliant

Obtenha o melhor preço

Hilink 10G Transceptor SFP+ de taxa de dados com distância de 30M/80M e módulo de cobre 10GBASE-T compatível com a RoHS

Obtenha o melhor preço

Hilink HL-SFP-T 1000BASE-T e 10/100/1000BASE-T Transceptor SFP de cobre com conector RJ-45

Obtenha o melhor preço

Contacte-nos

Contacte agora

Descrição do produto

Description

The HL-SFP-BXU-L5/HL-SFP-BXD-L5 Transceiver is intended for 5km reach service from 0.6Gb/s to 10.3125Gb/s BI-direction single mode high-speed communications equipment where low-cost, extraordinary performance and reliability are essential. It consumes low power, operates base on 3.3V DC power supply and is offered in the industrial temperature range. They are compliant with SFP28 MSA, SFF-8431 and SFF-8432.

The low jitter and low bit error rate optical assembly features a DML laser transmitter and PIN/TIA receiver. The differential AC coupled Tx and Rx data interfaces are CML compatible. The device is Class I laser safety compliant.

Product features

l Operating data rate up to 10.3125Gbps

l Up to 5km transmission distance

l High sensitivity PIN photodiode and TIA

l 12dB Power Budget at Least

l LC single connector

l Hot pluggable 20pin connector

l Low power consumption <1.2 W

l Single +3.3V±5% power supply

l Compliant with SFF-8472&SFF-8431

l Fully RoHS Compliant

l Compliant with IEEE802.3ae 10GBASE-LR/LW

l Operating temperature range:

Commercial: 0°C to +70°C

Industrial: -40°C to +85°C

Application

l 10GBASE-LR at 10.31Gbps

l 10GBASE-LW at 9.95Gbps

l Other Optical Links

SFP+ 10G BIDI 5KM Optical Transceiver with LC Connector for High-Speed Data Transmission 0

SFP+ 10G BIDI 5KM Optical Transceiver with LC Connector for High-Speed Data Transmission 1

SFP+ 10G BIDI 5KM Optical Transceiver with LC Connector for High-Speed Data Transmission 2
