Name: 200G QSFP DD PSM8 10km Optical Transceiver(MPO16)
Brand: Shenzhen HiLink Technology Co.,Ltd.
SKU: HL- 200G - DD - LR8
Price: 900.00 USD
Availability: InStock

Para casa > produtos > Transceptor de QSFP+ >

200G QSFP DD PSM8 10km Optical Transceiver(MPO16)

Lugar de origem:

Guangdong, China

Marca:

HILINK

Certificação:

CE FCC Rohs

Número do modelo:

HL- 200G - DD - LR8

Contacte-nos

Solicite um orçamento

Detalhes do produto

Nome do produto:

200G QSFP DD LR8

Aplicação:

Base 200GB

Comprimento de onda:

1310 nm

Distância:

10 km

DDM/DOM:

- Sim, sim.

Termos de pagamento e envio

Quantidade de ordem mínima

1pcs

Preço

Negociável

Detalhes da embalagem

Saco estático, saco de plástico, caixa varejo

Tempo de entrega

2-7 dias de trabalho

Termos de pagamento

T/T, Western Union, Paypal

Habilidade da fonte

10pcs/semana

PRODUTOS CONEXOS

Módulo Transceptor Óptico QSFP28 ER4 100Gb/s 40KM Hot Pluggable Duplex LC LAN WDM APD SMF compatível com RoHS-6

Obtenha o melhor preço

100Gb/s 100km QSFP28 Transceptor Hot Pluggable Duplex LC Connector LAN WDM EML TOSA SOA PIN SMF com FEC

Obtenha o melhor preço

Transceptor QSFP28 100Gb/s 80km Hot Pluggable Duplex LC Connector LAN WDM EML TOSA SOA PIN SMF

Obtenha o melhor preço

100Gb/s 60km QSFP28 Transceptor Hot Pluggable Duplex LC Connector EML+PIN com SOA DDM de modo único

Obtenha o melhor preço

Contacte-nos

86-755-8317-6243

Contacte agora

Descrição do produto

200G QSFP DD PSM8 10km Optical Transceiver(MPO16)

Features

l 8 channels full-duplex transceiver modules

l Supports 8×25Gb/s aggregate bit rates

l Supports 8×10Gb/s aggregate bit rates if required

l 8 channels 1310nm DFB

l 8 channels PIN photo detector array

l Internal CDR circuits on both receiver and transmitter channels

l Support CDR bypass

l Low power consumption <6.5W

l Hot Pluggable QSFP DD form factor

l Up to 10km reach for G.652 SMF

l Single male MPO16(APC 8-degree) connector receptacle

l Operating case temperature 0°C to +70°C

l 3.3V power supply voltage

l RoHS compliant (lead free)

Applications

l 2×100G Ethernet links

l Infiniband DDR/EDR

l Datacenter and Enterprise networking

Description

The Technologies HL-QSFP200G-LR8 is a Eight-Channel, Pluggable, Parallel, Fiber-Optic QSFP DD PSM8 for 2×100 Gigabit Ethernet , Infiniband DDR/EDR Applications. This transceiver is a high performance module for data communication and interconnect applications. It integrates eight data lanes in each direction with 208 Gbps bandwidth. Each lane can operate at 26Gbps up to 10km over G.652 SMF. These modules are designed to operate over single mode fiber systems using a nominal wavelength of 1310nm. The electrical interface uses a 76 contact edge type connector. The optical interface uses an 16 fiber MTP (MPO) connector. This module incorporates Hilink Technologies proven circuit and Optical technology to provide reliable long life, high performance, and consistent service.

QSFP SERIES :

QSFP	Nominal Wavelength (nm)	Cable Type	Core Size (Microns)	Modal Bandwidth (MHz^km)^3	Cable Distance^*1	Power Consumption (W)	Pull Tab Color
QSFP-100G-SR4-S	850	MMF	50.0 50.0	2000 (OM3) 4700 (OM4)	70m 100m	3.5	Beige
QSFP-100G-LR4-S	1295, 1300, 1304, 1309	SMF	G.652	-	10km	3.5	Blue
QSFP-100G-CWDM4-S	1271, 1291, 1311, 1331	SMF	G.652	-	2km	3.5	Green
QSFP-100G-PSM4-S	1310	SMF	G.652	-	500m	3.5	Orange
QSFP-100G-SM-SR	1271, 1291, 1311, 1331	SMF	G.652	-	2km	3.5	Green

200G QSFP DD PSM8 10km Optical Transceiver(MPO16) 0
